If you’re in pursuit of the ultimate helicopter simulator experience, the DOF Reality PRO 6 is the ideal professional-grade 6-axis motion simulator platform. Boasting top-tier design, precision engineering, superior quality, and unmatched performance, this system is meticulously crafted for customers who seek unparalleled immersion and the most realistic rotorcraft simulation available in 2026.
This model excels in helicopter simulation while also supporting fixed-wing flight and racing simulations without any drawbacks. The key innovation is the additional gearbox on each motor, providing extra smoothness and precision for the slow, delicate motions essential in helicopter flight — from hover drift and tail rotor corrections to coordinated turns, descent, and ground effect.
Our platform seamlessly integrates cutting-edge functionality with superior ergonomics, ensuring you experience the same adrenaline rush and physical sensations as in a real helicopter. Just like in a genuine rotorcraft, all controllers—including the cyclic, collective, throttle, pedals, joystick, yoke, and monitor—move together with the seat in our full-motion design, simulating authentic g-forces through muscle pressure points and body contact.
By choosing the PRO 6, businesses and enthusiasts can future-proof their setups with highly customizable Sim Racing Studio (SRS) software that delivers precise, telemetry-based feedback: runway bumps, turbulence, vibrations, rotor torque, collisions, ground effect, and more. The PRO 6 provides true six degrees of freedom (heave, roll, pitch, yaw with separate front and rear roll centers for body roll and yaw, surge, sway), faithfully replicating accelerations, climb, descent, coordinated turns, hover, and yaw corrections without relying solely on seat tilting — unparalleled in the market since DOF Reality pioneered affordable motion platforms in 2014, backed by outstanding warranty and 24/7 global support.
Why it stands out
True 6DOF Helicopter Motion
Heave, surge, sway, pitch, roll, and yaw with separate front/rear roll centers deliver complete rotorcraft realism: hover, drift, climb, descent, coordinated turns, and yaw corrections.
Gearbox-Enhanced Smoothness
Additional gearboxes provide ultra-smooth low-speed precision — critical for realistic helicopter hover, tail rotor inputs, and subtle flight maneuvers.
Full Cockpit Synchronization
Cyclic, collective, pedals, throttle, joystick/yoke, and monitor move with the seat for cohesive, lifelike g-force simulation through body pressure points.
Heli-Optimized SRS Telemetry
Sim Racing Studio converts real-time helicopter data into vivid cues: turbulence, rotor torque, ground effect, vibrations, collisions, and impacts.
Multi-Sim Versatility
Seamless performance in helicopter, fixed-wing flight, and racing simulators — no hardware changes required.
Commercial-Grade Reliability
Heavy-duty construction for intensive use, with 24/7 global support, full 1-year warranty, and final upgrade path.
What’s Included
DOF Reality PRO 6 – Ready-to-Play Package
P6 DOF Reality® ready to play includes:
- Rigid metal motors covers
- Metal rig for normal & F1 pose
- Mounts for seat or sliding rails
- Integrated power drive motors with gearbox enhancement
- 100-240 control unit with USB
- SimRacingStudio license
- Quick assembly tools
- 1 year full warranty
We sell only the plug-and-play motion platform. Customers provide their own seat, VR headset, and controllers (cyclic, collective, pedals, etc.) — the PRO 6 supports all major brands and types.
All necessary cables and motion software are included, but not the games/sim titles. For recommendations or component advice, visit our FAQ or contact the team via email/phone.
Specifications
Key specifications – DOF Reality PRO 6 (Helicopter Optimized)
| Degrees of Freedom (Axis) | 6DOF (Pitch, Roll, Yaw, Surge, Sway, Heave) |
|---|---|
| Full Platform Motion | YES |
| Range of Motion | 17° |
| Speed | 75 cm/s (105°/s) |
| Torque | 28 N/m |
| Acceleration | 0.5G all directions |
| Power Consumption | 1500 Watt (peak) |
| Box Weight (Size) | 1) 60kg (80 × 70 × 30cm) 2) 65kg (80 × 70 × 30cm) |
| Floor Footprint | 4×5 ft, 2 ft H (120×150 cm, 60 cm H) |
| Material Type | Commercial grade metal profiles |
| Supported Pilot Weight | 440 lbs / 200 kg |
| Warranty | Full 1 year |
| Upgradable | Final installment |
Available Options
Customize your DOF Reality PRO 6 helicopter motion simulator with compatible options to enhance protection, portability, immersion, and professional performance.
Extended Product Warranty (+1 Year)
Get extra peace of mind with our 1-year Extended Warranty! It adds coverage beyond the standard warranty, protecting your DOF Reality product from unexpected repair or replacement costs.
Why Choose It:
- Extra Coverage: Extends your warranty after the original one ends.
- Unexpected Protection: Covers sudden issues and malfunctions.
- Easy & Convenient: Quick support without searching for repair services.
- Peace of Mind: No worries about surprise expenses.
- Boost Resale Value: An active warranty can increase resale appeal.
Note: This warranty applies only to DOF Reality products and options. It does not cover third-party items like SRS, Sparco PFT, etc.
MagicBox for PS/XBOX motion
The MagicBox eliminates the need for a Windows PC by hosting SimRacingStudio directly—allowing your DOF Reality motion platform to receive motion data straight from PS or Xbox consoles. Simply connect the MagicBox and enjoy motion support in your favorite console racing or flight games. It works exclusively for motion control (not for peripherals like wheels or pedals) and is ideal for users who play console-only without a PC. You can even control SRS using your smartphone or tablet. Just plug in and race!
Sparco R100 Seat
The Sparco R100 is a modern update of Sparco’s popular steel-frame foldable seat, designed for comfort and versatility. Featuring enhanced side bolsters for improved support and updated padding for a more ergonomic feel, it’s built for performance and long sessions. The seat includes sliders and all necessary mounting hardware for quick and easy installation.
Sparco R333 Seat
The Sparco R333 combines modern style with enhanced comfort, making it a perfect match for today’s performance street cars. Designed with supportive bolsters and ergonomic padding, it ensures a secure and comfortable ride. Dual side levers allow easy seat adjustments, and integrated harness slots support 5- or 6-point seatbelts. The seat includes sliders and all required mounting hardware for easy installation.
Sparco Sprint Seat
The Sparco Sprint is an FIA-approved competition bucket seat, ideal for motion simulator setups. Designed to deliver safety, comfort, and value, it features a durable tubular steel frame and a suspension-style bottom cushion for excellent driving support. Compact shoulder bolsters fit smaller cockpits, while versatile mounting options include both bottom and side mounts—rare for an FIA-rated seat. Compatible with 5- or 6-point harnesses. Sized medium to accommodate up to a 34” waist. Includes side brackets, sliders, and all necessary hardware for installation.
4-point Harness (Red)
Add both style and safety to your simulator setup with this vibrant red 4-point harness. Crafted from durable 2-inch wide polyester webbing, it features ultra-light, high-strength steel adjusters, a precision aluminum buckle, and convenient snap-hook fastenings for quick and secure installation. Branded with the DOF Reality logo, this harness enhances both performance and immersion in your racing or flight simulation experience.
Monitor Mount
This VESA-compatible monitor mount (100 mm × 100 mm) supports a single monitor weighing up to 33 lbs (15 kg). It offers a stable and integrated display solution for your simulator setup.
Please ensure your platform is equipped with SFU gearboxes and the latest wide wheel support vertical bars before ordering.
eBreak Stop Button
The eBreak Emergency Stop Button is a vital safety feature designed to instantly halt all platform motion. Easily mountable within arm's reach, it provides quick and reliable shutdown in case of emergency. Fully compatible with all DOF Reality motion platform models.
Keyboard Holder
This adjustable keyboard holder is designed to securely mount onto the motion components of your rig, keeping your keyboard within easy reach during gameplay. It’s compatible with most keyboards, with the Logitech K400 Plus Wireless Keyboard with Touchpad being a popular choice among sim racers.
SRS UShake 6
SRS UShake 6 delivers ultra-realistic motion feedback through 6 built-in transducers, simulating suspension, engine vibrations, road textures, and more. Pre-wired and plug-and-play ready, it includes a 6-channel amp, sound card, and SRS App license for precise control. Ultra-quiet and compatible with most racing or flight seats, UShake 6 turns your sim setup into an immersive experience—no assembly needed. Just connect via USB and feel every bump, shift, and G-force.
SRS Hurricane Wind Package
The SRS Hurricane Wind Package significantly enhances the sim racing experience by delivering up to 30% greater wind speed compared to the standard “Double-the-fan” kit, incorporating 3-inch air straighteners. Constructed with a robust hard plastic casing, it is fully pre-assembled, including tubing and air straighteners. The package features accessories such as a GoPro 360 for the tube tip and an aluminum profile for the fan base. The system accurately replicates real driving sensations by automatically adjusting fan RPM to correspond with vehicle and track speeds at every 1 MPH or KPH increment. It includes all necessary hardware and software for immediate plug-and-play operation.
HOTAS Mounts kit
This mounting kit is designed for HOTAS flight control systems, including both throttle and joystick mounts. The joystick can be positioned either centrally or on the side, based on your preference. Compatible with all platform models except the M series, this kit offers a stable and ergonomic setup for an enhanced flight simulation experience.
Pedals Quick Release
Ideal for users who switch between flight and racing pedals, the Pedals Quick Release add-on allows for fast and effortless pedal swaps. In addition to enabling easy interchangeability, it also offers enhanced adjustability—allowing you to slide a single set of pedals forward or backward for optimal positioning. A convenient solution for maximizing flexibility and comfort in your simulator setup.
HoneyComb A+B adapter
This adapter is designed to securely mount the HoneyComb Alpha Yoke and Bravo Throttle onto our standard wheel plate. It ensures a precise fit and stable installation, allowing seamless integration of your HoneyComb flight controls into your simulator setup.
ProFlightTrainer Helicopter PUMA X
The Pro Flight Trainer PUMA X is an 8-axis USB helicopter control device designed for advanced immersion and precise, realistic inputs. Its compact, durable aluminum and steel frame ensures stability and portability. Featuring adjustable friction controls on wheel bearings, it offers ergonomic customization, including foldable cyclic grips and an inclined collective box with multiple switches. Compatible with major flight simulators and supporting driverless plug-and-play USB connection across Windows, Apple, and Linux, the PUMA X delivers high-resolution, accurate control inputs. Optional upgrades include twin-engine variants and toe brake kits. This device is ideal for pilots seeking realistic helicopter training and enhanced simulator performance.
Buttkicker Mount
Custom-designed mount for securely attaching a Buttkicker haptic transducer to your simulator platform. Ensures optimal placement for maximum vibration feedback and immersion.
Mat with DOF Reality Shield for 6 DOF Platform
This premium mat set includes nine (9) high-density rubber tiles, each measuring 19.5" x 19.5" and 0.5" thick (50 x 50 cm, 13 mm). Designed for 6 DOF platforms, the mat provides a cushioned, non-slip surface that minimizes vibration, reduces noise, and protects your flooring. Constructed from eco-friendly rubber granulate cubes, it offers excellent shock absorption, insulation from cold surfaces, and durability against weather conditions. Its anti-vibration and sound-isolating properties enhance simulator stability and realism—making it an essential addition to any immersive setup.
Lift Supports
This upgrade enhances the lifting capacity of 6 DOF systems by adding three heavy-duty lift supports along with a complete mounting kit. It is specifically recommended for users weighing over 300 lbs (136 kg) or when accommodating other substantial loads. This option ensures optimal performance and stability under increased weight conditions.
Transportation Wheels for 6 DOF Platforms
This portability upgrade adds two heavy-duty front wheels to your 6 DOF platform, allowing easy movement and transport. With this feature, a single person can lift the rear of the fully assembled platform, enabling the front wheels to engage the floor for quick relocation, loading, or unloading. Ideal for frequent repositioning at home or during events. Compatible with H6 and P6 platforms.
Cables Extension Set for 6 DOF Platforms
This cable extension set connects the control box to the motors on 6 DOF platforms. Standard cables are 1.2 meters (4 feet) long and sufficient for typical installations, with the control box ideally placed under the seat to simplify cable management. The extension set is intended for users who need to position the control box farther from the platform due to custom setups or specific space requirements. It ensures flexibility without compromising performance or cleanliness of your simulator layout.
FAQ
The PRO 6 delivers true 6DOF (heave, surge, sway, pitch, roll, yaw) with separate front/rear roll centers, gearbox-enhanced smoothness for low-speed precision, full-rig motion for authentic g-forces, and SRS telemetry optimized for helicopter cues like hover drift, tail rotor corrections, turbulence, and rotor effects.
Yes — it's fully versatile with complete 6DOF motion that handles flight climbs/descents, coordinated turns, and racing acceleration/braking/traction loss seamlessly, no hardware changes needed.
Full-motion rig moves everything together — seat, monitor, cyclic, collective, throttle, pedals, joystick/yoke — for cohesive, in-cockpit immersion and realistic g-force feedback.
Powered by Sim Racing Studio (SRS), it supports major titles like DCS World (helicopter modules), Microsoft Flight Simulator, X-Plane, and more via telemetry. Share your main sim for setup guidance.
Yes — its full 6DOF motion, smooth gearboxes, and robust build make it ideal for procedural training, muscle memory development, and commercial setups. For certified programs, verify local aviation authority requirements.
Footprint is approximately 120 × 150 cm (4 × 5 ft) with 60 cm height. Allow extra clearance (50–100 cm around) for motion travel, safe access, and peripherals.
Includes a full 1-year warranty with optional extension. 24/7 global support from DOF Reality ensures quick help with setup, tuning, or issues.
Shipping & Returns
Shipping overview
The DOF Reality PRO 6 Full 6DOF Motion Simulator Platform ships in multiple tracked boxes via courier or freight, depending on destination and configuration.
Shipping costs, delivery methods, and estimated lead times are calculated at checkout.
Processing & lead times
- Order processing times vary depending on stock status and configuration.
- Transit times depend on carrier, destination, and local customs clearance where applicable.
- High-demand periods or custom configurations may extend lead times.
Delivery considerations
- Packages may be heavy — two-person lifting is recommended.
- Ensure clear access for delivery and enough space for final placement and assembly.
- Freight shipments may be curbside delivery unless otherwise arranged.
Returns & exchanges
Motion simulator platforms are specialized equipment. Return eligibility, restocking fees, and return shipping responsibilities may vary based on condition, usage, and timing.
Before ordering, we strongly recommend confirming space requirements, PC or console compatibility, and any required accessories.
For full details or questions prior to purchase, please contact Support@AlphaCaveHQ.com.
Product Manuals
Manuals & setup guides
Manuals and documentation for the DOF Reality PRO 6 Helicopter will be provided here, including assembly, calibration, safety guidelines, and recommended maintenance.
- PRO 6 Assembly & User Manual – platform setup, calibration, and safety notes.
- Sim Racing Studio (SRS) Quick-Start Guide – connecting, configuring, and tuning motion profiles.
- Optional Accessories Guides – installation notes for seats, harness, mounts, covers, and more.
If you need documentation before manuals are posted, contact Support@AlphaCaveHQ.com.
